Panel Model |
EWIS SIB 85 |
LCD Size |
85” |
Resolution |
3840 × 2160 |
Display Area |
1872 (H) * 1053 (V) |
Response Time (Display) |
≤ 6ms |
Visual Ratio |
16:9 |
Color Depth/Saturation |
10Bit / 72% |
Refresh Rate |
60Hz |
Brightness |
400cd/m² |
Contrast Ratio |
4000:1 |
Lifetime |
50,000 hours |
Viewing Angle |
178° (H/V) |
Light Source |
DLED |
Tempered Glass |
Toughened Glass with level 7 Mohs Standard, 4mm (Anti-Glare Glass) |
Audio (Speakers) |
2 x 15W, 8 Ohms, Front-facing speakers |
System Version |
Android 14.0 |
CPU |
Octa Core ARM Cortex A55 1.9GHz |
GPU |
Mali G52 MP2(2EE) |
RAM |
8GB |
ROM |
128GB |
Built-in Camera |
48MP 4K Resolution Camera |
Microphone |
8 Array Microphones |
Wireless |
Frequency: 2.4GHz Ver 5.0, Distance: 0~10m |
Touch Specifications |
Infrared Non-Contact Multi-Touch technology |
Touch Points |
Up to 40 Points |
Input Mode |
Finger, Writing Pen, Hand with Gloves |
Respond Time (Touch) |
≤ 8ms (First Click) |
Communication Ports |
USB |
Touch Accuracy |
±1mm |
Ports |
Front: USB 3.0 * 3, HDMI 2.0 * 1, USB Touch * 1, Type-C * 1, Power ON/OFF Button Back: RJ45 * 1, HDMI 2.0 * 2, RS232 * 1, USB 3.0 * 1, Audio IN * 1, DP IN * 1, MIC IN * 1, TF-Card * 1, USB 2.0 * 1 Output: Earphone * 1, VGA OUT * 1, HDMI OUT * 1, RJ45 OUT * 1, Coaxial SPDIF (RCA) * 1, Touch OUT * 1 |
Power Supply |
100-240V ~ 50/60Hz 3.5A |
Power Consumption |
≤420W |
Standby Power Consumption |
≤0.5W |
Accessories |
Power Cord Remote Controller Stylus Pen * 2 Wall Mount Floor Stand Operation Manual |
Dimensions |
1953.56 x 1177.9 x 88.3 mm |
Net Weight |
66KG |
Gross Weight |
82KG |
Package Size |
2095 x 1320 x 220 mm |
warranty |
1 year warranty |
